Rockford Fosgate R2-500X4 Prime Series 4-Channel Car Amplifier
Rockford Fosgate R2-500X4 Prime Series 4-Channel Car Amplifier
Couldn't load pickup availability
Overview
- 4-channel car amplifier
- 75 watts RMS x 4 at 4 ohms
- 125 watts RMS x 4 at 2 ohms
- 250 watts RMS x 2 bridged output at 4 ohms (4-ohm stable in bridged mode)
- CTA-2006 compliant
- Class-D amplifier design
- variable high- and low-pass filters (50-250 Hz, 12 dB/octave) on front and rear channels
Details
Primed for Performance, the R2-500X4 is a 500 watt, full-range class-D amplifier, capable of operating at 4O or 2O stereo, and 4O bridged/mono. This amplifier is extremely efficient because of its class-D technology which reduces demand on the vehicles electrical system. The amp also features C.L.E.A.N. circuitry to help you adjust your gain settings, a P.O.W.E.R. Supply that generates more power as voltage increases.
The R2 models were developed for car audio fanatics that want a reliable amplifier – with all the power and performance you’ve come to expect from Rockford Fosgate – at an economical price. Rockford Fosgate amplifiers are renowned world-wide for being “under rated,” easily surpassing all specifications, and most importantly, generating more power than their ratings. These 3rd generation of Prime Series amplifiers are also designed to be easy to setup and configure, making them perfect for use with factory audio or custom aftermarket systems.
Product highlights:
- 4-channel car amplifier
- 75 watts RMS x 4 at 4 ohms
- 125 watts RMS x 4 at 2 ohms
- 250 watts RMS x 2 bridged output at 4 ohms (4-ohm stable in bridged mode)
- CTA-2006 compliant
- Class-D amplifier design
- variable high- and low-pass filters (50-250 Hz, 12 dB/octave) on front and rear channels
More Info:
- C.L.E.A.N. gain setup system includes clip lights
- auto remote turn-on
- preamp and speaker-level inputs
- preamp outputs
- wiring, fuse, and hardware not included with amplifier
- 4-gauge power and ground leads and an 80-amp fuse recommended
- dimensions: 10-1/16"W x 2"H x 7.75"D
Specifications
Performance | |
RMS Power Output (Watts x Channels) | 75 x 4 |
Peak Power Output (Watts x Channels) | N/A |
Power at 2 Ohms (Watts x Channels) | 125 x 4 |
Bridged Power (Watts x Channels) | 250 x 2 |
Minimum Impedance Bridged | 4 |
Minimum Impedance Unbridged | 2 |
Minimum Impedance | 2 |
Best Frequency Response | 20-20k Hz |
THD at Rated RMS Power | 1% |
Signal to Noise Ratio | 80 dB |
Input Voltage | 14.4v |
Features | |
Amplifier Class | D |
Low-Pass Crossover Frequency | 50-250 Hz |
Low-Pass Slope (dB/octave) | 12 dB/octave |
High-Pass Crossover Frequency | 50-250 Hz |
High-Pass Slope (dB/octave) | 12 dB/octave |
Bass Boost | No |
Bass Boost Frequency | N/A |
Fan Cooled | No |
Fuse Rating | 80 |
Speaker Level Inputs | Harness |
Preamp Outputs | 1 pair |
Width (inches) | 10-1/16 |
Height (inches) | 2 |
Depth (inches) |
7-3/4 |
