Rockford Fosgate Prime R250X1 Mono Sub Amplifier

Overview

• mono subwoofer amplifier
• 150 watts RMS x 1 at 4 ohms (250 watts RMS x 1 at 2 ohms)
• CEA-2006 compliant
• variable low-pass filter (50-250 Hz, 12 dB/octave)
• variable bass boost (0-12 dB at 45 Hz)
• phase switch
• wired remote Punch Level Control included

Details

The PRIME R250X1 is a mono amplifier featuring a compact chassis capable of producing 250 Watts of pure Rockford Fosgate power into 2-Ohms. The frequency response of the R250X1 allows it to be used exclusively with subwoofers.

The PRIME R250X1 amplifier is great mono amplifier in a compact chassis and respectable power output in any sound system. The R250X1 mono output design also makes it great for running a pair of 8" or 10" 4-ohm SVC subwoofers wired in parallel. The included Remote Punch Level Control corrects for any acoustic anomalies in the automobile environment, making certain that bass notes sound deep and rich.

Product highlights:

• mono subwoofer amplifier
• 150 watts RMS x 1 at 4 ohms (250 watts RMS x 1 at 2 ohms)
• CEA-2006 compliant
• variable low-pass filter (50-250 Hz, 12 dB/octave)
• variable bass boost (0-12 dB at 45 Hz)
• phase switch
• wired remote Punch Level Control included
• Class AB amplifier design
• frequency response: 20-250 Hz
• MOSFET power supply
• preamp and speaker-level inputs
• preamp outputs
• 8-gauge power and ground leads and a 30-amp fuse recommended — wiring and hardware not included with amplifier
• no on-board fuses — when installing multiple amps in a system, an additional 30-amp in-line fuse between the distribution block and this amplifier is recommended
• 11-1/4"W x 2"H x 7-3/8"D
