Product highlights: mono subwoofer amplifier 150 watts RMS x 1 at 4 ohms (300 watts RMS x 1 at 2 ohms) 500 watts RMS x 1 at 1 ohm CEA-2006 compliant Features: variable low-pass filter filter (50-250 Hz, 12 dB/octave) selectable subsonic filter (28Hz, 12 dB/octave) variable PEQ2 bass boost (0-18 dB at 45 Hz) C.L.E.A.N. gain setup system includes test tone CD test tones also available as MP3 download from Amazon On Demand, Rhapsody, Google Play, and Spotify, labeled "3sixty.3 setup disc" (Punch amps and the 3sixty.3 use the same test tone tracks for setup) Class-BD amplifier design frequency response: 20-250 Hz Dynamic Thermal Management and MEHSA MOSFET cooling systems MOSFET power and output stages preamp inputs and outputs speaker-level inputs (speaker wire to RCA adapter required) signal-sensing turn-on with speaker-level inputs eliminate need for remote turn-on lead
What's in the box: Rockford Fosgate Punch P500X1bd owner's manual
Mono subwoofer amplifier Four 1-1/2" Self-tapping screws 2.5mm Allen wrench Quick setup instructions Certificate of Performance
